Notes: Devices cannot be downgraded to versions lower than StoneOS 5.5R8P0.1,
otherwise the SIOM module will not be recognized by the system.
Ports
The ports available for Hillstone SG-6000-X series are Console port, Auxiliary port, USB port,
Cooper port, SFP port, XFP port, QSFP+ port, SFP+ port and QSFP28 port. This section
explains the attributes of each port.
Console Port
The modules supported by SG-6000-X10800 and SG-6000-X9180 provide two RS-232C asyn-
chronous serial console ports for you to configure the appliance. The modules supported by SG-
6000-X8180 provide one RS-232C asynchronous serial console ports for you to configure the
appliance. SG-6000-X7180 provides a RS-232C asynchronous serial console port for you to con-
figure the appliance.
Console Port Attributes
Attribute Description
Connector RJ-45
Port Standard RS
Baud Rate 9600/19200/38400/57600/115200 bit/s (SG-6000-X8180
only supports 115200 bit/s)
Services Connect the Con port to the serial port of a PC and run a ter-
minal emulation program on the PC to configure the appliance.
Transmission
Medium
Console Cable
44
Chapter 1 Product Profile
