Attribute
Description
Short-haul Multimode Optical
Module (850nm)
Medium-haul Single-mode
Optical Module (1310mm)
Connector MPO LC
Fiber Type 50/125um
OM3/OM4 multimode fiber
9/125um
single-mode fiber
Maximum
Transmission
Distance
0.1km (OM4)
0.07km(OM3)
10km（OM4）
Central
Wavelength
850nm 1294.53nm–1296.59nm
1299.02nm–1301.09nm
1303.54nm–1305.63nm
1308.09nm–1310.19nm
Notes: To avoid dust falling into the QSFP28 socket, you should place a rubber
dust cap (originally in the accessory box) over the QSFP28 port.
SD Card Slot
Hillstone SG-6000-X7180 has an SD card slot for SD storage card on the front panel. SD card
stores the data of the Network Behavior Control log messages. The highest capacity for SD card
on the device is 32GB.
To install an SD card, take the following steps:
1. Ensure that the write protection switch is off so that it can be written.
2. Face the front panel of the appliance.
3. Insert the SD card with the metal contact side facing down and push it slightly into the card
slot. Do not push too hard with force to avoid damage to the slot or the card.
52
Chapter 1 Product Profile
