LED Color/Status Description
ACT Orange/Blinking The port is sending or receiving data.
Off No data is transmitted on this port.
Front
Slots 1 - 6
Green/Blinking The expansion module is working normally.
Red/Always on The expansion module has an error.
Orange/Blinking The expansion module is starting.
Rear Slots
7 - 10
Green/Blinking The expansion module is working normally.
Red/Always on The expansion module has an error.
Orange/Blinking The expansion module is booting.
SC0 Green/Blinking SCM in the slot SC0 serves as the master mod-
ule and is working normally.
Orange/Blinking SCM in the slot SC0 serves as the backup mod-
ule and is working normally.
Red/Always on SCM in the slot SC0 has an error.
SC1 Green/Blinking SCM in the slot SC1 serves as the master mod-
ule and is working normally.
Orange/Blinking SCM in the slot SC1 serves as backup module
and is working normally.
Red/Always on SCM in the slot SC1 has an error.
Chapter 1 Product Profile 17
