Attribute Description
Connector QSFP+
Frame Format Ethernet_II
Ethernet_SNAP
Negotiation
Mode
QSFP+ optical module 40Gbps
The following types of QSFP+ optical module are supported. The optical modules are available
with LC-type connectors and are all hot-swappable.
QSFP+ Optical Module Attributes is shown as below:
Attribute
Description
Short-haul Multimode
Optical Module
(850nm)
Short-haul Multimode
Optical Module
(850nm)
Ultra-long Haul Single-
mode Optical Module
(1550nm)
Connector MPO LC
Fiber Type 50/125μm
multimode fiber
50/125μm
multi-mode fiber
9/125μm
single-mode fiber
Maximum
Transmission
Distance
0.1km (OM1) 0.3km(OM3) 10km
Central
Wavelength
850nm 850nm 1310nm
Notes: To avoid dust falling into the QSFP+ socket, you should place a rubber dust
cap (originally in the accessory box) over the QSFP+ port.
Chapter 1 Product Profile 49
