6.2 Saving Data
131
3
Chapter 6 Saving & Loading Data
6
Setting configurations can be saved as data files and later reloaded into the
HiLogger when you need to make more measurements with the same settings.
Up to ten setting configurations can be saved to internal memory, and more
can be stored on the removal storage device.
To Save a Setting Configuration
Select the [Setting] Screen.
Select [Save Set]
Apply
The Save dialog appears.
1
2
3
Select whether to save to
HiLogger memory, CF
card, or USB flash drive.
Apply
4
Setting configuration files are automat-
ically named CONFnnnn.SET in a fold-
er named [HIOKI_LR8400]-[CONFIG]
(p. 121).
(When [Memory] is selected)
Select [Save] for the con-
figuration instance (No.)
to save.
Enter a comment as needed
(p. 71).
Apply
(When [CF Card], or [USB memory] is
selected)
Comments entered on the [Comment] screen
are displayed here.
See: To reload a setting configuration (p. 132)
To Next Page
