Traffic control
Basic - L3P
Release
3.1
06/07
8.4
Prioritization
147
Configuration of Weighted Fair Queuing and Traffic Shaping
enable
configure
no cos-queue strict 0 1 2 3
4 5
cos-queue min-bandwidth 10
10 15 15 20 30 0 0
cos-queue max-bandwidth 20
20 20 20 20 30 30 30
ex
show interfaces cos-queue
Switch to the privileged EXEC mode.
Switch to the configuration mode.
Disable Strict Priority for the priority classes 0 to 5
and thus enable Weighted Fair Queuing. The prio
-
rity classes 6 and 7 remain in Strict Priority mode.
Assigns the weighting to the Weighted Fair Queu-
ing priority classes. In the case of Strict Priority,
because the Switch first transmits all the data
packets with a high priority, you can enter the
weighting 0 for the Strict Priority priority classes
and distribute 100% among the remaining priority
classes. The Switch distributes the remaining
bandwidth in accordance with the percentage
weighting.
Assigns a maximum bandwidth to all priority
classes (Shaping).
Because the two Strict Priority priority classes are
limited to a maximum of 30%, the remaining
queues have at least 40% of the bandwidth at their
disposal. The Switch immediately sends Strict Pri
-
ority data up to a maximum bandwidth of 30%.
Switch to the privileged EXEC mode.
Display the configuration.
Global Configuration
Interface Shaping Rate......................... 0
Queue Id Min. Bandwidth Max. Bandwidth Scheduler Type
-------- -------------- -------------- --------------
0 10 20 Weighted
1 10 20 Weighted
2 15 20 Weighted
3 15 20 Weighted
4 20 20 Weighted
5 30 30 Weighted
6 0 30 Strict
7 0 30 Strict
