Access to the user interfaces
16
1.1
System monitor
Basic - L3P
Release
3.1
06/07
1.1 System monitor
The system monitor enables you to
D select the boot operating software,
D update the operating software,
D start the selected operating software,
D end the system monitor,
D erase the saved configuration and
D show the bootcode information.
U Opening the system monitor
V Using a terminal cable (see accessories) connect the
– V.24 RJ11 socket to
– either a terminal or a COM port of a PC with terminal emulation
according to VT 100
(For the physical connection refer to the “Installation user manual“.).
V Start the terminal program on the PC, and establish a connection with
the Switch.
While booting the Switch the message „Press <1> to enter System
Monitor 1“ appears on the terminal.
Speed 9.600 Baud
Data 8 bit
Parity none
Stopbit 1 bit
Handshake off
Table 1: Data transfer parameters
