8.6.4 Displaying the VLAN configuration

8.6.5 Deleting the VLAN settings

V Select the Switching:VLAN:Current dialog.

The Current table displays all locally configured VLANs

and VLANs configured by GVRP.

V Select the Switching:VLAN:Global dialog.

The “Delete” button in the VLAN global dialog allows you to restore

all the default VLAN settings of the device (state on delivery).

V Select the Switching:VLAN:Static dialog.

The “Delete” button in the VLAN static dialog allows you to delete a

selected row of the table.
