Traffic control

158

8.6

VLANs

Basic - L3P

Release

3.1

06/07

8.6.6 Example of a simple VLAN

The following example provides a quick insight into configuring a VLAN that

is commonly found in practice.

The configuration is explained step by step.

Fig. 43: Example of a VLAN

149.218.112.208

149.218.112.76

VLAN Yellow

VLAN Green

VLAN Brown

ID = 1

Network

Management

Station
