Operation Diagnostics
172
9.2
Monitoring Device Status
Basic - L3P
Release
3.1
06/07
It depends on the management setting which events cause a contact to
switch.
Note: With non-redundant supply of the mains voltage, the Switch reports a
power failure. You can prevent this message by applying the supply voltage
over the two inputs or by switching off the monitoring
(see “Monitoring correct operation via the signal contact” on page 176).
V Select the Diagnostics:Device Status.
V Select in the frame “Monitoring correct operation” the events which
you want to have monitored.
V For temperature monitoring set in the Basics:System dialog at the
end of the system data the temperature thresholds..
Configure Device Status
enable
configure
device-status monitor all en
able
device-status trap enable
Switch to the privileged EXEC mode.
Switch to the configuration mode.
Includes all the possible events in the device sta-
tus determination.
Enables a trap to be sent if the device status
changes.
Display Device Status
exit
show device-status
Switch to the privileged EXEC mode.
Displays the device status and the setting for the
device status determination.
