Entering the IP parameters
36
2.3
Entering the IP parameters via HiDiscovery
Basic - L3P
Release
3.1
06/07
When HiDiscovery is started, it automatically searches the network for those
devices which support the HiDiscovery protocol.
HiDiscovery uses the first PC network card found. If your computer has se-
veral network cards, you can select these in HiDiscovery on the toolbar.
HiDiscovery displays a line for every device which reacts to the HiDiscovery
protocol.
HiDiscovery enables you to identify the devices displayed.
V Select a device line.
V Click on the symbol with the two green dots in the tool bar to set the LEDs
for the selected device flashing. To Switch off the flashing, click on the
symbol again.
By double-clicking a line, you open a window in which you can enter the de-
vice name and the IP parameter.
Fig. 11: HiDiscovery - assigning IP parameters
Note: After the IP address has been entered, the Switch loads the local con-
figuration settings (see “Loading/saving settings” on page 51).
Note: For security reasons, Switch off the HiDiscovery function for the device
in the Web-based interface, after you have assigned the IP parameters to the
device (see
“System configuration via the Web-based Interface” on page 47).
Note: Save the settings you have made so they will still be available after re-
start (see “Loading/saving settings” on page 51).
