9. Connecting Cables
NOTICE: Take full care to connect cables correctly.
Route the cables not to affect the maintenance part replacement.
Because operation of the Storage System is affected by the cable routing, follow the “Note at the Time of
Cable Routing” (INST(GE)01-01-30).
NOTE : • Power supply system of the Storage System is duplicated.
It is recommended to connect each system to outlet of one of the two power sources
independent of each other.
• Do not connect a cable to the console port of the ENC (SBX/UBX/FBX).
Otherwise, a failure might occur.
The cable connection of the Storage System that is mounted on the rack frame is shown in Figure 9-1 or later.
Table 9-1 shows the types of the cables to be connected.
Table 9-1 Types of Cables to be Connected
No. Cable name Remarks
1 Fibre Channel cable See “9.1.1 Connecting Fibre Channel Cables”.
2 iSCSI cable See “9.1.2 Connecting iSCSI Cables”.
3 X path cable See “9.2 Connecting X-Path Cables”
4 LAN cable See “9.3 Connecting LAN Cables”
5 SAS cable/NVMe cable See “9.4 Connecting SAS Cables/NVMe Cables”.
6 Power cable See “9.5 Connecting Power Cables”.
7 Power cable (for rack frame PDU) See “9.6 Connecting Power Cables (Rack Frame PDU)”.
