7.2 Fixing Drive Box
(
SBX/UBX/NBX
)
The components for xing the Drive Box are included in the Front Bezel. Check the table of the components
list.
Table 7-3 Front Bezel Components List (Per Unit)
Item No. Parts name Parts No. Quantity Comment
1 Front Bezel 5560002-A 1 Front Bezel (SBX/UBX/NBX)
2 Side bezel (R) 2855176-001 1 For right hand side
(For SBX/UBX/NBX)
3 Side bezel (L) 2855177-001 1 For left hand side
(For SBX/UBX/NBX)
4 Bracket (R) 3290548-001 1 For right hand side
5 Bracket (L) 3282470-001 1 For left hand side
6 Binding Screw (M5 × 10) SB510N 5
(*1)
For xing the Drive Box and the
bracket
7 COINLOCK MINI (R) KEY 3276491-001 1
(*2)
Key for Front bezel
*1 : 1 spare is included.
*2 : One pair (two keys)
