Hitachi DKC910I - Page 113

Copyright © 2019, 2021, Hitachi, Ltd.
DKC910IHitachi Proprietary
[INST(IN)09-01-30]
Rev.0.5
INST(IN)09-01-30
Figure 9-2 Cable Connection (CHB:Fibre Channel) (DKC
×
2 + HSNBX
×
2 + SBX/FBX)
*1: This is a connection example when connecting a power cable to PDU6 (breaker rating: 10 A).
：iSCSI cables
：SAS cables
：Power cables
