1. Cable types and selection criteria
(1) There are two types of X-path cables: copper and optical cables. The following table lists the cable
models.
Table 9-3 List of X-Path Cables
No. Cable model Cable length (m) Quantity Type Remarks
1 DKC-F910I-MCC1/MCC1P 0.6 8 Copper DKC-0 ~ HSNBX
(for CBXA)
2 DKC-F910I-MCC60/MCC60P 0.6 4 Copper DKC-0 ~ HSNBX
(for CBX)
3 DKC-F910I-MCC2/MCC2P 0.45 8 Copper DKC-1 ~ HSNBX
(for CBXB)
4 DKC-F910I-MCC45/MCC45P 0.45 4 Copper DKC-1 ~ HSNBX
(for CBX2)
5 DKC-F910I-MPC5/MPC5P 5 8 Optical
6 DKC-F910I-MPC10/
MPC10P+SQSFP/SQSFPP
10 8 Optical
7 DKC-F910I-MPC20/
MPC20P+SQSFP/SQSFPP
20 8 Optical
8 DKC-F910I-MPC30/
MPC30P+SQSFP/SQSFPP
30 8 Optical
9 DKC-F910I-MPC1H/
MPC1HP+SQSFP/SQSFPP
100 8 Optical
(2) The copper cables can be used only when all the following conditions are met. For the other cases,
use the optical cables.
(a) Connection between DKC-0 and HSNBX, and connection between DKC-1 and HSNBX.
(For connections between DKC-2 through 5 and HSNBX, use the optical cables.)
(b) DKC-0, DKC-1, HSNBX-0, and HSNBX-1 are adjacently installed in a 10U space in a rack in
the same layout shown below. The installation conguration is called the basic 10U.
Figure 9-11 Basic 10U Conguration
HSNBX-1
HSNBX-0
DKC-1
DKC-0
10U
2U
4U
4U
Basic 10U
