INST(IN)09-04-40
• The additional DKC (CBX Pair 1: DKC-2/DKC-3, CBX Pair 2: DKC-4/DKC-5) and SBX/FBX/
NBX are installed with a gap of 2U or less.
Table 9-10 SAS Cable/NVMe Cable Connection and Copper Cable Length (CBX Pair 1)
DKC Controller chassis DKB DBx Copper
Cable length
DKC-3 CTL32 32D-0 DB068/069-ENC2-IN1 1.2 m
32D-1 DB070/071-ENC2-IN1 1.2 m
32H-0 DB064/065-ENC2-IN1 1.2 m
32H-1 DB066/067-ENC2-IN1 1.2 m
CTL31 31D-0 DB068/069-ENC1-IN1 1.5 m
31D-1 DB070/071-ENC1-IN1 1.5 m
31H-0 DB064/065-ENC1-IN1 1.5 m
31H-1 DB066/067-ENC1-IN1 1.5 m
DKC-2 CTL22 22D-0 DB068/069-ENC2-IN0 1.2 m
22D-1 DB070/071-ENC2-IN0 1.2 m
22H-0 DB064/065-ENC2-IN0 1.2 m
22H-1 DB066/067-ENC2-IN0 1.2 m
CTL21 21D-0 DB068/069-ENC1-IN0 1.5 m
21D-1 DB070/071-ENC1-IN0 1.5 m
21H-0 DB064/065-ENC1-IN0 1.5 m
21H-1 DB066/067-ENC1-IN0 1.5 m
Table 9-11 SAS Cable/NVMe Cable Connection and Copper Cable Length (CBX Pair 2)
DKC Controller chassis DKB DBx Copper
Cable length
DKC-5 CTL52 52D-0 DB132/133-ENC2-IN1 1.2 m
52D-1 DB134/135-ENC2-IN1 1.2 m
52H-0 DB128/129-ENC2-IN1 1.2 m
52H-1 DB130/131-ENC2-IN1 1.2 m
CTL51 51D-0 DB132/133-ENC1-IN1 1.5 m
51D-1 DB134/135-ENC1-IN1 1.5 m
51H-0 DB128/129-ENC1-IN1 1.5 m
51H-1 DB130/131-ENC1-IN1 1.5 m
DKC-4 CTL42 42D-0 DB132/133-ENC2-IN0 1.2 m
42D-1 DB134/135-ENC2-IN0 1.2 m
42H-0 DB128/129-ENC2-IN0 1.2 m
42H-1 DB130/131-ENC2-IN0 1.2 m
CTL41 41D-0 DB132/133-ENC1-IN0 1.5 m
41D-1 DB134/135-ENC1-IN0 1.5 m
41H-0 DB128/129-ENC1-IN0 1.5 m
41H-1 DB130/131-ENC1-IN0 1.5 m
