[INST(IN)03-01-140]
Figure 3-16 Installing Rails for HSNBX (with Stopper)
Rack frame (rear side)
Stopper
Rack frame (rear side)
Binding screw (M5 × 10)
Clip
Pin
Clip
Pin
Rail (R)
Rack frame
(front side)
Unit boundary
Unit boundary
Unit boundary
Unit boundary
Pin
Pin
Loop cable tie
