Figure 4-3 Attachment of Nameplates and Label
HSNBX
Item No. 3 Item No. 1
Item No. 5
Item No. 7
Item No. 8
Rear
Front
Top View
HPE
HPE
Hitachi Vantara
Hitachi Vantara
LABEL (REGULATORY)
NAMEPLATE
HSN Box Chassis
MDKC9101-HSNBX
2857688-028
Primary Controller Chassis
DKC9101-CBXA
2857688-001
XXXXXXXX
HSN Box Chassis
2857688-021
R0K80-63002
LABEL (BIS)
Item No. 9
Front
Rear
