Copyright © 2019, 2021, Hitachi, Ltd.
DKC910IHitachi Proprietary
[INST(IN)06-02-20]
Rev.0
INST(IN)06-02-20
5. After mounting the Storage System on the rack frame, lower the elevating base to the lowermost position
by gently opening the up/down valve of the special lifter and take off the stopper of the lifter.
6. Move the special lifter to the place where the lifter does not disturb the following works.
Figure 6-3 Mounting Storage System on Rack Frame
Handle
Valve
Stopper
Base
Storage System to be mounted
Rack frame
Push in
To Next Page
