2. Fixing Controller Chassis
(1) When installing DKC, x each of the right and left places on the front side of DKC with four bind
screws.
(2) For the rail type without a stopper, go to Step 3 to install the stoppers.
Figure 7-2 Fixing the Front Side of DKC
Binding screws
Binding screws
Rev.1
INST(IN)07-01-20
