2-6
Note: *1 When the ink type is set, an initial value is automatically set.
With respect to full details about the excitation curve, refer to the
attached figure 8.6.
*2 The excitation curve value that has been initially set can be changed later.
If excitation curve “00” has been chosen, a constant value irrelevant to
the ambient temperature will be output with the “Excitation V Update”
screen (see the table below). If the excitation curve is set to a
value other than the initial one, printing may be abnormal: After
finishing maintenance work, reset the value to the original.
PXR-D PXR-P TYPE
Constant excitation voltage output values (set on the “Excitation V update” screen)
Setting value 00 01 02 03 04 05 06 07 08 09
Excitation voltage (V) 90 104 118 133 147 161 175 189 204 218
Setting value 10 11 12 13 14 15 16 17 18 19
Excitation voltage (V) 232 246 260 275 289 303 317 331 346 360
PXR-H TYPE
Constant excitation voltage output values (set on the “Excitation V update” screen)
Setting value 00 01 02 03 04 05 06 07 08 09
Excitation voltage (V) 40 52 64 76 88 100 112 124 136 148
Setting value 10 11 12 13 14 15 16 17 18 19
Excitation voltage (V) 160 172 184 196 208 220 232 244 256 268
