1-13
1.3.5 Print head
Note: Meaning of orifice plate lot number
6 A12345
Serial number
Nozzle diameter
6: 65μm
4:
40μm
1:100μm
5:
55μm
Print head
(
PXR-H
)
Pipe
g
utte
r
Plus deflection electrode
Nozzle
(
55µm
)
Minus deflection electrode
Position of
lot numbe
r
Orifice plate
