3-6
[EZJ104 board external views]
Connector for
EZJ97 board
Memory card slot
Connector for touch panel
Connector for LCD
harness
Connector for
EZJ93 board
Connector for
battery connection
Connector for
inverter board
F1
F2
REG1
PS2
Fixing screw
(
4 locations
)
Fixing screw
(4 locations)
Fixing screw
(
4 locations
)
Fixing screw
(4 locations)
