7.3 Faults – Print-stop type
7.3.1 Print Overlap Fault

Perform a reset to clear the
fault.
Print Overlap Fault
Is the next printing
sequence timed before
completion of the current
one?
Is the time interval between
the end of a printing operation
and the beginning of the next
printing operation less than 10
ms?
Set the time interval between the
end of a printing operation and
the beginning of the next
printing operation to 10 ms or longer.
Set the repeat printing intervals
to the printing time plus 10 ms or
longer.
Replace the EZJ93 board.
No
Y
es
Y
es
Y
es
No
Perform sensor filter setup.
Y
es
No
Resume the
operation.
Is the print start signal
chattering?
A
re the repeat printing
intervals less than the
printing time plus 10 ms with
the repeat printing mode
selected?
No
