7-1
7. Troubleshooting
7.1 Troubleshooting List
Subsection Name Screen Error Code Nr.
7.2 Faults – Ink-stop type
7.2.1 Ink Low 001
7.2.2 Main Ink Tank Too Full 002
7.2.3 Makeup Ink Low 011
7.2.4 Replenishment Timeout 010
7.2.5 Ink Drop Charge Too Low 005
7.2.6 No Ink Drop Charge 016
7.2.7 Noise Fault M/S 007/008
7.2.8 Deflection Voltage Leakage 009
7.2.9 Deflection Voltage Fault 003
7.2.10 DC Power Supply Fan Fault 013
7.2.11 Charge Voltage Fault 015
7.2.12 Internal Communication Error S 022
7.2.13 F Memory Fault M/S/9 020/ 030/ 019
7.2.14 Hardware Error C 021
7.2.15 Ink Heating Too High 012
7.2.16 Heating Unit Sensor Fault 017
7.2.17 Ink Heating Current Fault 024
7.2.18
Ambient Temperature Sensor Fault 025
7.2.19
Viscometer Temperature Sensor Fault 032
7.2.20
Pump Motor Fault 031
7.2.21 Cooling Fan Fault 026
7.3 Faults – Print-stop type
7.3.1
Print Overlap Fault
049
7.3.2 Cover Open 050
7.3.3 Improper Sensor Position 051
7.3.4 Target Sensor Fault 052
7.3.5 Target Spacing Too Close 053
7.3.6 Print Data Changeover In Progress S/C/M/V 054/ 055/ 058/ 059
7.3.7 Blank Print Items 056
7.3.8 Excessive Format Count 057
7.3.9 Substitution Character Undefined 061
7.3.10 Ink Drop Charge Too High 042
7.3.11 Internal Communication Error C/M 062/ 063
7.4 Warning conditions (printing continuously performed)
7.4.1 Ink Shelf Life Exceeded 083
7.4.2
Operating Temperature Too High/Too Low
084/ 085
7.4.3 Ink Heating Too Low 086
7.4.4 Battery Low 088
7.4.5 Product Speed Matching Error 095
6.4.6 Ink pressure Low 093
7.4.7 Ink Pressure High 087
7.4.8 Viscosity Reading Instability 066
7.4.9 Viscosity Readings Out of Range 067
7.4.10 High Ink Concentration 068
7.4.11 Low Ink Concentration 069
7.4.12 Excitation V-ref. Review 065
7.4.13
High Air Pressure 094 (PXR-P only)
7.5 Faults – No on-screen indications
7.5.1 Chipped print (lower dots)
7.5.2 Chipped print (upper dots)
7.5.3 Varying character height
7.5.4 Increased character distortion
7.5.5 Disordered characters
7.5.6 Ink leakage/blowout
7.5.7
Printing initiation failure in ready state
7.5.8 No ink ejection from nozzle
