4-5
5 Remove the fixing screws (4 positions) of the main ink tank and take out
the main tank.
"Caution" Put wiping paper under the main ink tank to provide for an ink
drip.
6 Clean the portion stained with ink and then install the main ink tank by
reversing the above procedure.
7 Perform “Ink refill” and make sure that there is no ink leak.
Main ink tank
Fixing screws
Fixing screws
