Hitachi RAS-(4-12)HNP(1)(E) User Manual

2 Unit Installation
20
SMGB0087 rev.0 - 12/2013
2.5 Installationspace(Initialckeck)
 N O T E
Thefollowingimagesareforillustrationpurposesonly.
2.5.1 Basic sizes

RAS-2HVNP1 - RAS-2.5HVNP1 - RAS-3HVNC1
≥
≥
≥≥ ≥≥
50
200
250
100
100200

RAS-(4-6)H(V)NC1E)

All models (except RAS-2HVNP1 - RAS-2.5HVNP1 - RAS-3HVNC1 - RAS-(4-6)H(V)NC1E)
Units in mm.
600
200
50
200600
100
50
600
200
300600
100
