Hitachi RAS-(4-12)HNP(1)(E) User Manual

9 Spare parts
330
SMGB0087 rev.0 - 12/2013
No. Partname Remarks
1 Rear Cover L Assy Assembly
1-1 Handle
1-2 H Cover
1-3 Pipe Cover B
2 Upper Cover Assy Assembly
3 Service Cover L Assy Assembly
4 S Cover B Lower Service Cover
5 Protector Net L Assy
6 Shroud L Unit Assembly
6-1 Shroud L Shroud
6-2 Front Protector Net Air Outlet
7 Clamp L Assy
8 Fan Motor MOF1, DC100W,8P
9 Fan Motor MOF2, DC100W,8P
10 Propeller Fan Ø544
11 B-Base Assy Assembly
12 Compressor
E402HHD-36A2
(RAS-(4-6)HVNP1E)
E402HHD-36D2
(RAS-(4-6)HNP1E)
13 C Heater 240V-52W
14 Acoustical Cover
15 Acoustical Cover Upper Cover
16 Acoustical Cover Lower Cover
17 Vibration Absorber
18 Vibration Absorber
19 Special Nut
20 Rubber Cap
21 Condenser
Assembly (Heat exchanger
+ 21-1+21-2)
21-1 Header L Unit Assembly
21-1-1 EVO Assy Assembly
21-1-1-1 Expansion Valve EVO
21-1-1-2 Strainer
21-2 Header G Unit Assembly
22 EXPV Coil Coil for Expansion Valve
23 Stay
24 End P Unit
25 Partition Assy
26 Tank Assy
9.4.3 Parts name

Cycle and structural parts
No. Partname Remarks
27 Strainer
28 Pressure SW for Low Pressure
29 Coil 20 Coil for Solenoid Valve
30 Coil Coil for 4-Way Valve
31 4-Way Valve Assy Assembly
31-1 D Pipe Unit
31-1-1 Check Valve
31-1-2 Silencer
31-1-3 Pressure SW PSH (High)
31-1-4 P-Sensor PSC (Control)
31-2 SVC Assy
31-2-1 Solenoid Valve SVA
31-3 SVA Assy
31-4 4 Way Valve RVR
31-5 Check JA
31-6 Stop Valve For liquid line 3/8
31-7 Stop Valve For gas line 5/8
31-8 Valve Stay
32 V-Stay
33 Thermistor
for Outdoor Temperature,
THM7
34 Thermistor
for Pipe Temperature,
THM8
35 Thermistor
for Discharge Gas Tempe-
rature THM9
36 TH-Plate
