CacheInfo.csv
This CSV le contains information about the cache memory on the controller board. A
r
ecord is created for each cache memory.
Table 15 CacheInfo.csv le (Title: <<Cache>>)
Item Content
Location Name of the cache controller board on which the memory is installed
CMG#0 Size (GB)
CMG#1 Size (GB)
Cache memory capacity in the controller board per CMG (16/32/64/128/
blank). The number of CMG diers by model and the displayed items are
dierent.
■
VSP G200
: Only CMG#0 Size displays
■
VSP G400, G600, G800 or VSP F400, F600, F800: CMG#0 Size and CMG#1
Size display
Depending on the installed number of the cache memory (DIMM), one of
the CMG capacities might be blank for VSP G400, G600, G800 or VSP F400,
F600, F800.
Cache Size (GB) Total cache memory capacity on the controller board (0 to 256)
SM Size (MB) The capacity that cannot be used as data cache memory in the total cache
memory capacity inside of the contr
oller board.
The capacity per cluster is displayed.
Includes the shared memory capacity, cache directory capacity, and the
xed capacity.
Fixed capacity is the cache memory capacity that is used for controlling the
storage system with the controller board.
■
VSP G200: (0 to 18944)
■
VSP G400, G600 or VSP F400, F600: (0 to 37888)
■
VSP G800 or VSP F800: (0 to 47744)
CFM#0 Type
CFM#1 Type
Type of CFM in the cluster (BM 10/BM 20/BM 30/blank). The number of
CFM diers by model and the number of the displayed items are dierent.
■
VSP G200
: CFM#0 type only
■
VSP G400, G600, G800 or VSP F400, F600, F800: CFM #0 Type or CFM#1
Type
Depending on the installed CFM number, one of the CFM types might be
displayed as blank.
Information about the NAS module is not displayed in this CSV le.
CacheInfo.csv
Appendix A: Examples of storage conguration reports
System Administrator Guide for VSP Gx00 models and VSP Fx00 models 243
