Table 52 PECBInfo.csv le (Title: <<PECB Information>>)
Item Content
Location PECB location name
Status Whether the PECB is installed
■
Installed
■
Not Installed
Type Destination module type of the PECB
■
CHBB
Expansion mode Expansion mode set in the destination module of the PECB
■
1:2
PkInfo.csv
This CSV
le contains information about channel boards (CHBs). A record is created for
each CHB.
Table 53 PkInfo.csv le (Title: <<PK>>)
Item Content
CHB Location CHB name
CHB-1A/1B/1C/1D or CHB-2A/2B/2C/2D if "Package T
ype" is NAS module.
Port# Number of the port installed on the CHB (2-digit hexadecimal number)
Port Name of port installed on the CHB
Package Type CHB type indicated on the CHB Location
■
Fibre: 8FC4 (CHB), 16FC2 (CHB), 32FC4R (CHB)
■
iSCSI: 10iSCSI2o (CHB), 10iSCSI2c (CHB)
■
NAS module: NAS module (CHB)
SFP Kind SFP (Small Form factor Pluggable) Kind
■
Short Wave
■
Long Wave
■
Blank if "Package Type" is 10iSCSI2c (CHB) or NAS module (CHB).
PkInfo.csv
