Hitron CGNM-2250 User’s Guide
3.6 The DOCSIS Event Screen
Use this screen to discover information about:
The nature of the upstream and downstream connection between the CGNM-
2250 and the device to which it is connected through the CABLE interface.
IP details of the CGNM-2250’s WAN connection.
Click Status > DOCSIS Event. The following screen displays.
Port ID This displays the ID number of the upstream
connection’s port.
Frequency (MHz) This displays the actual frequency in Megahertz (MHz)
of each upstream data channel to which the CGNM-
2250 is connected.
Modulation This displays the type of modulation that each upstream
channel uses.
Signal Strength
(dBmV)
This displays the power of the signal of each upstream
data channel to which the CGNM-2250 is connected, in
dBmV (decibels above/below 1 millivolt).
Channel ID This displays the ID number of each channel on which
the upstream signal is transmitted.
BandWidth This displays the BandWidth of each upstream channel
to which the CGNM-2250 is connected.
Table 13: The Status: DOCSIS WAN Screen (continued)
