Hitron CGNM-2250 User’s Guide
Subnet Mask Use this field to define the LAN subnet. Use dotted
decimal notation (for example, 255.255.255.0).
LAN DHCP Status Use this field to configure whether or not the CGNM-
2250’s DHCP server is active.
 To turn the DHCP server on, click Enabled.
 To turn the DHCP server off, click Disabled.
Lease Time This displays the time that elapses before your device’s
IP address lease expires, and a new IP address is
assigned to it by the DHCP server.
DHCP Start IP Use this field to specify the IP address at which the
CGNM-2250 begins assigning IP addresses to devices
on the LAN (when DHCP is enabled).
DHCP End IP Use this field to specify the IP address at which the
CGNM-2250 stops assigning IP addresses to devices
on the LAN (when DHCP is enabled).
NOTE: Devices requesting IP addresses once the
DHCP pool is exhausted are not assigned an IP
address.
Save Changes Click this to save your changes to the fields in this
screen.
Cancel Click this to return the fields in this screen to their last-
saved values without saving your changes.
Help Click this to see information about the fields in this
screen.
Connected Devices
Host Name This displays the name of each network device
connected on the LAN.
IP Address This displays the IP address of each network device
connected on the LAN.
MAC Address This displays the Media Access Control (MAC) address
of each network device connected on the LAN.
Type This displays whether the device’s IP address was
assigned by DHCP (DHCP-IP), or self-assigned.
Interface This displays whether the device is connected on the
LAN (Ethernet) or the WLAN (Wireless(x), where x
denotes the wireless mode; b, g or n).
Table 16: The Basic: LAN Setup Screen (continued)
