Hitron CGNM-2250 User’s Guide
Protocol Use this field to specify whether the CGNM-2250 should
forward traffic via:
Transmission Control Protocol (TCP)
User Datagram Protocol (UDP)
Transmission Control Protocol and User Datagram
Protocol (TCP/UDP)
Generic Routing Encapsulation (GRE)
Encapsulating Security Protocol (ESP)
NOTE: If in doubt, leave this field at its default (TCP/
UDP).
Public Port Range Use these fields to specify the incoming port range.
These are the ports on which the CGNM-2250 receives
traffic from the originating host on the WAN.
Enter the start port number in the first field, and the end
port number in the second field.
To specify only a single port, enter its number in both
fields.
Private Port Range Use these fields to specify the ports to which the
received traffic should be forwarded.
Enter the start port number in the first field. The number
of ports must match that specified in the Public Port
Range, so the CGNM-2250 completes the second field
automatically.
Local IP Address Use this field to enter the IP address of the computer on
the LAN to which you want to forward the traffic.
Remote IP Use this field to configure the IP address range on the
WAN from which traffic is forwarded.
Remote IP Range
Rule Status Use this field to turn port forwarding rule on or off.
Apply Click this to save your changes to the fields in this
screen.
Close Click this to return to the Port Forwarding screen
without saving your changes to the port forwarding rule.
Table 19: The Basic: Port Forwarding Add/Edit Screen
