D2 Drive User Guide v1.8 7. LCD Operation
HIWIN Mikrosystem Corp. 217
LCD
No.
Parameter
Definition
Unit
Default
Max.
Min.
358
#
AT.stiff
Stiffness setting for the second
generation of Auto tune
1: Soft
2: Normal
3: Rigid
--
2
3
1
359
#
X_Mbus_Bau
dRateIndex
Baud rate for the Modbus
communication
0: 9,600 (default)
1: 2,400
2: 4,800
3: 9,600
4: 14,400
5: 19,200
6: 38,400
bps
0
6
0
360
X_Mbus_Slav
e_Addr
Drive station number (for Modbus)
--
0
247
0
361
#
X_Mbus_SetP
arity
Check setting for the Modbus parity
0: 8 data, Even parity, 1 stop bit
1: 8 data, Odd parity, 1 stop bit
2: 8 data, None parity, 2 stop bit
3: 8 data, Even parity, 1 stop bit
4: 7 data, Odd parity, 1 stop bit
5: 7 data, None parity, 2 stop bit
6: 7 data, Even parity, 1 stop bit
--
0
6
0
362
X_Mbus_T15
Maximum time interval for the Modbus
RTU character
ms
3
2
31
-1
1
363
X_Mbus_T35
Minimum time interval for the Modbus
RTU frame
ms
4
2
31
-1
1
364
X_TMO_Scale
Output scale of analog output 1
%
100
300
1
365
X_TMO_Offs
Output offset of analog output 1
mv
0
10,000
-10,000
366
X_VMO_Scal
e
Output scale of analog output 2
%
100
300
1
367
X_VMO_Offs
Output offset of analog output 2
mv
0
10,000
-10,000
368
UserPDL.X_fV
ar[0]
PDL parameter which can be saved in
Flash
--
0
3.4X10
38
-3.4X10
38
369
UserPDL.X_fV
ar[1]
PDL parameter which can be saved in
Flash
--
0
3.4X10
38
-3.4X10
38
370
UserPDL.X_fV
ar[2]
PDL parameter which can be saved in
Flash
--
0
3.4X10
38
-3.4X10
38
371
UserPDL.X_fV
ar[3]
PDL parameter which can be saved in
Flash
-
0
3.4X10
38
-3.4X10
38
372
UserPDL.X_fV
ar[4]
PDL parameter which can be saved in
Flash
--
0
3.4X10
38
-3.4X10
38
373
UserPDL.X_iV
ar [0]
PDL parameter which can be saved in
Flash
--
0
2
31
-1
-(2
31
- 1)
374
UserPDL.X_iV
ar [1]
PDL parameter which can be saved in
Flash
--
0
2
31
-1
-(2
31
- 1)
375
UserPDL.X_iV
ar [2]
PDL parameter which can be saved in
Flash
--
0
2
31
-1
-(2
31
- 1)
376
UserPDL.X_iV
ar [3]
PDL parameter which can be saved in
Flash
--
0
2
31
-1
-(2
31
- 1)
377
UserPDL.X_iV
ar [4]
PDL parameter which can be saved in
Flash
--
0
2
31
-1
-(2
31
- 1)
378
UserPDL.X_iV
ar [5]
PDL parameter which can be saved in
Flash
--
0
2
31
-1
-(2
31
- 1)
