D2 Drive User Guide v1.8 4. Wiring
HIWIN Mikrosystem Corp. 54
4.2. Drive accessories
(1) Motor power cable
Table 4-13
Part name
Part No.
Description
Motor power
cable
HVPS04AA□□MB
Suitable for 50 W - 750 W motor, without brake, flexible.
HVPM04BA□□MB
Suitable for 1KW motor, without brake, straight connector,
flexible.
HVPM04BB□□MB
Suitable for 2KW motor, without brake, straight connector,
flexible.
HVPM04CA□□MB
Suitable for 1KW motor, without brake, L-type connector,
flexible.
HVPM04CB□□MB
Suitable for 2KW motor, without brake, L-type connector,
flexible.
HVPS06AA□□MB
Suitable for 50 W - 750 W motor, with brake, flexible.
HVPM06BA□□MB
Suitable for 1KW motor, with brake, straight connector,
flexible.
HVPM06BB□□MB
Suitable for 2KW motor, with brake, straight connector,
flexible.
HVPM06CA□□MB
Suitable for 1KW motor, with brake, L-type connector,
flexible.
HVPM06CB□□MB
Suitable for 2KW motor, with brake, L-type connector,
flexible.
 denotes the cable length as follows:
Table 4-14

03
05
07
10
Cable length (m)
3
5
7
10
(2) Encoder cable
Table 4-15
Part name
Part No.
Description
Encoder cable
HVE13IAB□□MB
Suitable for 50 W - 750 W motor, 13-bit incremental,
flexible.
HVE13IBB□□MB
Suitable for 1 KW - 2 KW motor, 13-bit incremental,
straight connector, flexible.
HVE13ICB□□MB
Suitable for 1 KW - 2 KW motor, 13-bit incremental, L-type
connector, flexible.
HVE17IAB□□MB
Suitable for 50 W - 750 W motor, 17-bit incremental,
flexible.
HVE17IBB□□MB
Suitable for 1 KW - 2 KW motor, 17-bit incremental,
straight connector, flexible.
HVE17ICB□□MB
Suitable for 1 KW - 2 KW motor, 17-bit incremental, L-type
connector, flexible.
HVE17AAB□□MB
Suitable for 50 W - 750 W motor, 17-bit absolute, flexible.
HVE17ABB□□MB
Suitable for 1 KW - 2 KW motor, 17-bit absolute, straight
connector, flexible.
HVE17ACB□□MB
Suitable for 1 KW - 2 KW motor, 17-bit absolute, L-type
connector, flexible.
HE00817DR300
3 m in length, suitable for frame A-C models with the
dual-loop encoder, flexible.
