Hologic Selenia - Emergency off Switches; Figure 6: Emergency off Switch; Figure 7: Acquisition Workstation Emergency off Switch; Figure 8: Value Console Emergency off Switch

Selenia User Guide
Chapter 3—System Components and Controls
MAN-03270 Revision 003 23
3.3.2 Emergency Off Switches
• Press any Emergency Off Switch to remove
Gantry power.
• Rotate the switch one-quarter turn to reset.
•
Restart the system after any Emergency Off
Switch is pressed. (See the procedure in
Restart After the Emergency Off Switch was
Activated on page
38.)
Figure 6: Emergency Off Switch
Figure 7: Acquisition Workstation Emergency Off
Switch
Figure 8: Value Console Emergency Off Switch
Figure 9: Gantry Emergency Off Switches
