Selenia User Guide
Chapter 3—System Components and Controls
24 MAN-03270 Revision 003
3.4 Acquisition Workstation Controls and Display
3.4.1 Acquisition Workstation
Figure 10: The Acquisition Workstation
Controls
Figure 11: The Selenia Value Console Controls
Figure Legend
1. Circuit Breaker
2. Emergency Off Switch
3. Selenia Display
4. Trackball
5. CD-RW Drive
6. Left and Right Keypads
7. Selenia Acquisition Workstation UPS
(Uninterruptible Power Supply) Reset
Button (on lower right back)
8. Bar Code Scanner
9. Selenia Keyboard
Figure Legend
1. Computer
2. Bar Code Scanner
3. Left and Right Keypads
4. Keyboard
5. Display
6. Emergency Off Switch
7. Mouse
8. Circuit Breaker
9. CD-RW Drive
10. UPS
