Selenia User Guide
Chapter 3—System Components and Controls
MAN-03270 Revision 003 29
The Compression Device contains the
AEC Sensor control and position LEDs,
and displays compressed breast
thickness and force. Handwheels allow
manual compression control.
The rear edges of the C-arm Side Rail
have recessed push-button controls for
motorized compression and C-arm
movement. An additional C-arm
Rotation button is available on the rear
of the Image Receptor.
3.5.2.1 Compression Device Controls and Displays
Figure Legend
1. Compression Handwheels
2. AEC Sensor Position Controls
3. AEC Sensor Position Display
4. Compression Force Display
5. Compression Thickness Display
Figure 17: Compression Device
