Selenia User Guide
Chapter 5—The Selenia Accessories
MAN-03270 Revision 003 43
Chapter 5
Chapt er 5 The Selenia Accessories
5.1 Patient Face Shield
Remember to examine the Face Shield condition before use each day.
5.1.1 How to Install the Face Shield on the Tubehead
1. Put the tab ends on the open end of the Face Shield into the slots on the tubehead
mount.
2. Slide the Face Shield into the tubehead mount until the Face Shield locks in position.
5.1.2 How to Remove the Face Shield
1. Pull the rear sides of the shield away from the tubehead.
2. Slide the shield off the mount.
Figure 27: Installation of the Face Shield
Warning:
The Face Shield must be attached for all exposures
except magnification case studies.
Warning:
The Face Shield does not protect the patient from
radiation.
