Selenia User Guide
Chapter 3—System Components and Controls
30 MAN-03270 Revision 003
3.5.3 Dual Function Footswitches
1. Press the footswitch to activate.
2. Release the footswitch to stop
motorized movement.
Figure Legend
1. C-arm Down
2. C-arm Up
3. Compression Down
4. Compression Up
Figure 18: The Dual Function Footswitch
Warning:
Put the footswitches away from the patient and
C-arm area to prevent any accidental footswitch
operation. When the
patient has a wheelchair, put the
footswitches away from the area.
