6-10
5) Remove the two 4 x 6 mm screws from the brush holder
assembly and remove the brush holder assembly.
Remove the brush holder insulator from the brush holder
assembly.
[1]
BRUSH HOLDER
INSULATOR
[3]
BRUSH
HOLDER
ASSEMBLY
[2]
4 x 6 mm
SCREW (2)
6) Remove the two 4 x 25 mm screw-washers and the 4 x 6
mm screw from the IC regulator, then remove the IC
regulator.
[3] 4 x 6 mm SCREW
[2]
4 x 25 mm SCREW-
WASHER (4)
[1]
IC REGULATOR
