Honeywell CK65 Series - S0803-LR Flexrange XLR Imager Field of View;Resolution

102 CK65 Mobile Computer User Guide
Typical Specs
S0803-LR FlexRange XLR Imager Field of View/Resolution
Note: DPI can be calculated based on the following formula:
Horizontal DPI = 1920 pixels/width of horizontal field of view (inches)
Vertical DPI = 800 pixels/width of vertical field of view (inches)
100 mils Data Matrix
1
mm - 6500
in. - 255.91
1
Minimum distance depends on the length of the barcode.
2
Typical code wide to narrow elemental ratio is 3:1. Minimum 100 mils code height of 3 inches
Focus Standard Range
Symbology Near Distance Far Distance
5 mils Code 39 mm 125 469
in. 4.92 18.46
10 mils Data Matrix mm 140 441
in. 5.51 17.36
10 mils Code 128 mm 88 2021
in. 3.46 79.57
13 mils UPC-A mm 56 2090
in. 2.20 82.28
20 mils Code 39 mm 60 6341
in. 2.36 249.65
55 mils Code 39
1
mm - 15425
in. - 607.28
100 mils Code 39
1, 2
mm - 26197
in. - 1031.38
100 mils Data Matrix
1
mm - 11718
in. - 461.34
1
Minimum distance depends on the length of the barcode.
2
Typical code wide to narrow elemental ratio is 3:1. Minimum 100 mils code height of 3 inches.
Focus Standard Range
Symbology Near Distance Far Distance
Near Field Focus
Horizontal Field Angle (degrees) 48°
Vertical Field Angle (degrees) 21°
