106 CK65 Mobile Computer User Guide
N6803-FR FlexRange Imager Field of View/Resolution
Note: DPI can be calculated based on the following formula:
Horizontal DPI = 1920 pixels/width of horizontal field of view (inches)
Vertical DPI = 800 pixels/width of vertical field of view (inches)
N6703-SR Standard Range Imager Reading Distances
The depth of field measurements were taken using these parameters:
• Distances are measured from the front of the engine
• +23 °C (+73 °F), 0 lux
• Photographic quality codes
Note: Time to Read and Depth of Field are impacted if the barcode symbol is at the edge of
the image.
10 mils Data Matrix mm 135 419
in. 5.31 16.5
13 mils UPC-A mm 60 1600
in. 2.36 62.99
15 mils Code 128 mm 58 1894
in. 2.28 74.57
20 mils Code 39 mm 56 2645
in. 2.2 104.13
55 mils Code 39
1
mm - 7159
in. - 281.85
100 mils Code 39
1, 2
mm - 10815
in. - 425.78
100 mils Data Matrix
1
mm - 5641
in. - 222.09
Focus Standard Range
Symbology Near Distance Far Distance
1
Minimum distance depends on the length of the barcode.
2
Typical code wide to narrow elemental ratio is 3:1. Minimum 100 mil code height of 3 inches.
Focus
Horizontal Field Angle (degrees) 48
Vertical Field Angle (degrees) 21
