DR4300 Circular Chart Recorder

222 DR4300 Circular Chart Recorder Product Manual 4/00

Lower Display

Prompt

Upper Display

Range of Setting

or Selection

Parameter

Definition

Continue to configure ramp segments (odd-numbered) and soak segments (even-numbered) through

Segments 23 and 24.

SG23RP

0 to 99 hours:0 to 59 min

(if RPUNIT = TIME)

0 to 999 degrees per minute

or hour (if RPUNIT = EU-M

or EU-H)

[factory setting = 0.00]

SEGMENT 23 RAMP VALUE—Enter the ramp time or

ramp value for Segment 23.

SG24SP

range depends on setpoint

limits [factory setting = 0]

SEGMENT 24 SETPOINT—Enter the setpoint for

Segment 24.

SG24TI

0 to 99 hours:0 to 59 min

[factory setting = 0]

SEGMENT 24 TIME—Enter the duration for Segment 24
