61 Safety Bus Manual — P/N LS10177-000HI-E:B 02/21/2019
Hardware, Installation, and Wiring Diagrams
Figure 7.5 SB-SIM/GM, SB-SIM, SB-NCM, and SB-SCM Dimensions
Figure 7.6 SB-AIM Dimensions
101.15 [3.98]
77 [3.03]
SB-SIM/GM, SB-SIM, SB-NCM, SB-SCM
Suppression Board
Use with S81-T9001-1 Transient
53 [ 2.08 ]
167 [ 6.57 ]
· Operating temperature: 0 / +49 °C (32 / 120.2 °F)
· Storage temperature: -55 / +85 °C (-67 / 185 °F)
· Max humidity: 0-95% non-condensing
· Protection rating: IP30
· Mounting: T35 DIN rail
· Dimensions: 53 x 167 x 100 (W x H x D mm)
· Weight: approx. 600g
· Connections: 2.5mm² removable terminal blocks
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
S81-T9001-1-R0
RV17RV18RV19R V21RV20RV22RV23RV24
RV16
RV14
RV12
RV11
RV9
RV7
RV4
RV3
RV15
RV13
RV10
RV8
RV6
RV5
RV2
RV1
BR1BR2
TB1
4KW1
FIRE ALARM SUBASSEMBLY
UOXX
EMERGENCY SIGNALING SUBASSEMBLY
FSYE
INSTALL IN ACCORDANCE WITH INSTALLATION
INSTRUCTIONS LS10177-000HI-E
LS10203-000HI-E:A ECN: 17-XXX
4KW1
FIRE ALARM SUBASSEMBLY
UOJZ
EMERGENCY SIGNALING SUBASSEMBLY
FSZI
INSTALL IN ACCORDANCE WITH INSTALLATION
INSTRUCTIONS LS10139-051HI-E AND
LS10177-000HI-E
LS10202-000HI-E:A ECN: 17-XXX
SB-AIM
Suppression Board
Use with S81-T9004-1 Transient
53 [ 2.08 ]
167 [ 6.57 ]
· Operating temperature: 0 / +49 °C (32 / 120.2 °F)
· Storage temperature: -55 / +85 °C (-67 / 185 °F)
· Max humidity: 0-95% non-condensing
· Protection rating: IP30
· Mounting: T35 DIN rail
· Dimensions: 53 x 167 x 100 (W x H x D mm)
· Weight: approx. 600g
· Connections: 2.5mm² removable terminal blocks
146 [5.75]
77 [3.03]
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
17
18
19
21
20
22
23
24
TB1
BR2 BR1
4KW1
FIRE ALARM SUBASSEMBLY
UOXX
EMERGENCY SIGNALING SUBASSEMBLY
FSYE
INSTALL IN ACCORDANCE WITH INSTALLATION
INSTRUCTIONS LS10177-000HI-E
LS10203-000HI-E:A ECN: 17-XXX
4KW1
FIRE ALARM SUBASSEMBLY
UOJZ
EMERGENCY SIGNALING SUBASSEMBLY
FSZI
INSTALL IN ACCORDANCE WITH INSTALLATION
INSTRUCTIONS LS10139-051HI-E AND
LS10177-000HI-E
LS10202-000HI-E:A ECN: 17-XXX
