Page #14 background imageLoading...
Page #14 background image
14 www.honeywell.com
NetAXS™ NX4L1 Installation Guide
Notices
1.6 Underwriters Laboratories Incorporated
The NetAXS panel was approved by Underwriters Laboratories Incorporated for
Access Control System Units - Category ALVY, UL294 standard. The NetAXS panel
was approved as a standalone system. The input points only monitor the door position.
The NetAXS panel is not intended as a Proprietary Alarm Unit - Category APOU,
UL1076 standard.
The NetAXS panel was approved using the following Honeywell readers:
OmniAssure™ OT30, OmniClass™ OM40 and OM55, and OmniProx™ OP30 and
OP40.
Notes:
All field wiring, except for the AC power input and the battery backup/charger
wiring, is Class 2 power-limited.
Communication between panels other than the NetAXS panel has not been
evaluated by UL.
UL has approved only the configurations shown in Section 5.1, "RS-485
Connection via PCI-2" on page 42, Section 5.2, "RS-485 Connection via
NetAXS" on page 43, and Section 5.4, "RS-232 Connection" on page 46 of this
guide. Because UL has approved the NetAXS panel only as a standalone system,
the computer terminal, NetAXS gateway panel, and N-485_PCI-2 adapter appear
in these sections only to illustrate the installation and programming of the
NetAXS panel.
UL has not evaluated the compatibility of downstream I/O devices (see Section
4.10, "Downstream I/O" on page 39) with the NetAXS panel.
All wiring methods shall be performed in accordance with NFPA70, local codes
and authorities having jurisdiction.
This product must be mounted indoors only, installed within the protected
premises.
This product must be installed, serviced and tested once a year by a factory trained
professional.
All interconnecting devices must be UL Listed and Class 2 power-limited only.
The minimum system configuration consists of Model NX4L1 and a Listed,
compatible access control reader or keypad.
The system shall not be installed in the fail secure mode unless permitted by the
local authority having jurisdiction and shall not interfere with the operation of
panic hardware.
The model NX4L1 system is capable of providing 40 minutes of standby power.
The model NX4L1 system is capable of being permanently connected to line
voltage or alternatively a cord connection can be made. The cord shall be a
minimum 6 ft. long and a SJ, SJT, or equivalent.
