NetAXS™ NX4L1 Installation Guide
Installation
NetAXS™ NX4L1 Access Control Unit Installation Guide, Document 7-901099V3 37
4.8 DIP Switch Settings
Figure 16 locates the NX4L1 DIP switch panel and the J36 and J37 jumpers.
Figure 16: DIP Switch and Jumper Location
J36
J37
DIP
Switches
