76 www.honeywell.com
NetAXS™ Standalone Operation
NetAXS Panel Defaults
4.3 Reader Tamper Inputs
The card readers have a Tamper signal wired to the NetAXS™ panel. This is a
two-state input configured as a Normally Closed contact.
The following are the default Reader Tamper Input to Panel Input associations:
4.4 Door Egress Inputs
The panel has a Request-To-Exit (egress) input for each door. The default condition is
a two-state input configured as Normally Closed contact. When the egress input is
active, the associated output relay will be active.
The following are the default egress input associations:
Tamper LED Reports as...
Tamper 1 Input 9
Tamper 2 Input 10
Tamper 3 Input 11
Tamper 4 Input 12
Egress input Controls relay... Panel input Reports as...
1 1 SP1 Input 1
2 2 SP3 Input 3
3 3 SP5 Input 5
4 4 SP7 Input 7
