NetAXS™ NX4L1 Installation Guide
Installation
Figure 7: NetAXS Panel Cabinet, Right View
3 11/16"
(93.5 mm)
1 5/8"
(41 mm)
0
0
0
0
2 9/16" (65 mm)
4 23/32" (120 mm)
6 11/16" (170 mm)
8 21/32" (220 mm)
10 10/16" (270 mm)
15 3/4" (400 mm)
17 23/32" (450 mm)
22 3/8" (568mm)
20 11/32" (517 mm)
17 3/16" (436.87" mm)
20 1/8" (511.5 mm)
20 15/16" (532 mm)
2 19/32" (65 mm) 1 31/32" (50 mm) 31/32" (25 mm)
1 19/32" (40.1 mm)
1 3/16" (30.5 mm)
13/16" (21 mm)
Back
