NetAXS™ NX4L1 Installation Guide
Installation
NetAXS™ NX4L1 Access Control Unit Installation Guide, Document 7-901099V3 25
Figure 6: NetAXS Panel Cabinet, Left View
0
1 5/8"
(41 mm)
2 5/32" (55 mm)
0
2 9/16" (65 mm)
4 23/32" (120 mm)
4 17/32" (115 mm)
6 11/16" (170 mm)
8 21/32" (220 mm)
10 10/16" (270 mm)
16 30/32" (430 mm)
18 29/32" (480 mm)
22 3/8" (568.5 mm)
31/32" (25 mm)
Back
